SD175SAP-12SH 172x150x51mm / 6.7x2inch Sinwan DC Fan, 320~125 CFM

SD175SAP-12SH 172x150x51mm / 6.7x2inch Sinwan DC Fan, 320~125 CFM

SD175SAP-12SH 172x150x51mm / 6.7x2inch Sinwan DC Fan, 320~125 CFM

To Favourites
Recommend
Print
Question about the product
Ask about it
Details
Info
Details

  Motor Type: Microprocessor brushless DC Motor, auto cutoff, auto restart
  Burnout Protection: Electronically protected, polarity protected
  IP Protection: IP68 optional request
  Frame: Aluminum die cast, black color(AP) or natural color(AN)
  Impeller: 5 blades, glass fiber reinforced plastic, rated UL94V-0
  Bearing: Two ball bearings
  Rotation: CW seen on rotor
  Connection: Wire lead or terminal flat pin connecting
  Weight: 820 g (1.8 Lbs)
  Dielectric Strength: 500 VAC/min. Max leakage 500mA
  Speed Control: Optional:PWM, S/C NTC thermister, S/V (0~10V) speed control on request
  Signal Output: Optional:R/D alarm output, tachometer output
  Operating Temp: Ambient non-condensing -15~+65C
  Storage Temp: -25C~+80C (at 65%RH)
  Life Expectancy: L10 90K hours at 35C, 40K hours at 60C

http://sinwan.eu

Info
Article No.
SD175SAP-12SH
