SD6025SPT 60x60x25mm / 2.36x1.0inch Sinwan DC Fan, 56 CFM

SD6025SPT 60x60x25mm / 2.36x1.0inch Sinwan DC Fan, 56 CFM

SD6025SPT 60x60x25mm / 2.36x1.0inch Sinwan DC Fan, 56 CFM

To Favourites
Recommend
Print
Question about the product
Ask about it
Details
Info
Details

  Motor Type: DC Motor
  Burnout Protection: Electronically protected, Polarity protected
  IP Protection: IP55, 68 optional request
  Frame: Glass fiber reinforced thermoplastic, rated UL94V-0
  Impeller: 7 blades, glass fiber reinforced thermoplastic, rated UL94V-0
  Bearing: Two ball bearings
  Rotation: CCW seen on rotor
  Connection: Wire lead or terminal flat pin connecting
  Weight: 60g
  Dielectric Strength: 500 VAC/min. Max leakage 5mA
  Speed Control: PWM, On request
  Signal Output: Optional: R/D alarm output, Tachometer output
  Operating Temp: -10~+70C
  Storage Temp: -40~+75C
  Life Expectancy: L10 70K hours at 40C

http://sinwan.eu

Info
Article No.
SD6025SPT
