Sinwan Heat resistant AC skeleton fan metal impeller reverse airflow MK254GAN

Sinwan Heat resistant AC skeleton fan metal impeller reverse airflow MK254GAN

Sinwan Metal Impeller, Reverse Airflow, Heat Resistant AC skeleton fan. Best quality. MK254GAN

To Favourites
Recommend
Print
Question about the product
Details
Info
Details

  Motor Type: Capacitor induction, 2 or 4 pole
  Burnout Protection: Thermal protector
  IP Protection: IP56
  Frame: Aluminum die cast, black cosmetics. Natural or any colors available
  Impeller: Steel-sheet metal fan blades, integrantly spot welded onto rotor
  Bearing: System: Two high precision permanently lubricated ball bearings
  Rotation: CCW seen on rotor
  Connection: Wire lead
  Weight: 1,900g (4.2Lbs)
  Dielectric Strength: Over 1 minute at 1,500 VAC, 0.5mA, 50/60 Hz
  Insulation Resistance: Over 100 MΩ at DC 500V
  Signal Output:
  Operating Temp: Ambient non-condensing -30~+80C
  Storage Temp: -40C~+100C (at 65%RH)
  Life Expectancy: 50K hours at 55C

http://sinwan.eu

Info
Article No.
MK254GAN
