MED8025PT05-MB Sinwan motor

Motor Type: Brushless DC, polarity protected,impendance locking proteted,auto cutoff protection option

IP Protection: IP55 optional request

Frame: Glass filber reinforced thermoplastic PBT case and frame, rated UL94V-0

Bearing: Two high precision permanently lubricated ball bearings

Shaft: Stainless steel SUS420J2, dia.3mm,15mm out, Customer design available

Weight: 45 Gm (0.09Lb)

Dielectric Strength: Over 1 sec. at 500VAC, maximum leakage 500 micro Amp.

Insulation Resistance: Over 10 mega Ohm at DC 500V between leads and frame

Speed Control: -

Operating Temp: Acceptable -25°C~+65°C. Storage -30°C~+90°C (at 65%RH)

Life Expectancy: 80K hours at 45°C, 50K hours at 60°C. MTBF life 100K hours at 55°C

DC / DR / UC / UR / DUC / DUR / NC / NR, for full model No. click “Nomenclature”.
First *=D, U, DU, N description of shaft outlet position, second *=C, R description of motor rotating direction C-CW , R-CCW.
Example: MED8025PT12-HBDR, **/DR= Shaft outlet- D type, motor rotating direction viewed from rotor CCW-R type

Sinwan reserves the right to change data and improve electrical & mechanical design without notice, data tolerance +-10%
