MK280GAN (HR) - Sinwan AC Skeleton Fan, Metal Impeller, Dia.245x100mm / 9.6inch 1300~450 CFM

MK280GAN (HR) - Sinwan AC Skeleton Fan, Metal Impeller, Dia.245x100mm / 9.6inch 1300~450 CFM
MK280GAN (HR) - Sinwan AC Skeleton Fan, Metal Impeller, Dia.245x100mm / 9.6inch 1300~450 CFM
MK280GAN (HR) - Sinwan AC Skeleton Fan, Metal Impeller, Dia.245x100mm / 9.6inch 1300~450 CFM
MK280GAN (HR) - Sinwan AC Skeleton Fan, Metal Impeller, Dia.245x100mm / 9.6inch 1300~450 CFM
Rated
Volt		 Voltage
Range		 Freq Input
Power		 Ref.
Speed		 Max.Airflow Max.Static Pressure Noise
Level		 PQ
Model No VAC VAC Hz Watt

RPM

 CFM m3/min Inch/H2O mm db(A)
MK280GAN11-1** 115 100~120 50/60 155/210 2800/3200 1150/1300 32.6/36.8 1.2/0.75 30.48/19.05 74
MK280GAN11-2** 115 100~120 50/60 95/110 2400/2500 1000/1050 28.3/29.7 1.02/0.59 25.91/14.99 62
MK280GAN11-3** 115 100~120 50/60 32/43 1500/1600 620/650 17.6/18.4 0.53/0.45 13.46/11.43 46
MK280GAN11-4** 115 100~120 50/60 26/35 1200/1100 460/450 13/12.7 0.25/0.35 6.35/8.89 34
MK280GAN11-1/2**
Dual speed		 115 100~120 50/60 155/210
95/110		 2800/3200
2400/2500		 1150/1300
1000/1050		 32.6/36.8
28.3/29.7		 1.2/0.75
1.02/0.59		 30.48/19.05
25.91/14.99		 74
62
MK280GAN11-3/4**
Dual speed		 115 100~120 50/60 32/43
26/35		 1500/1600
1200/1100		 620/650
460/450		 17.6/18.4
13/12.7		 0.53/0.45
0.25/0.35		 13.46/11.43
6.35/8.89		 46
34
MK280GAN22-1** 230 200~240 50/60 155/210 2800/3200 1150/1300 32.6/36.8 1.2/0.75 30.48/19.05 74
MK280GAN22-2** 230 200~240 50/60 95/110 2400/2500 1000/1050 28.3/29.7 1.02/0.59 25.91/14.99 62
MK280GAN22-3** 230 200~240 50/60 32/43 1500/1600 620/650 17.6/18.4 0.53/0.45 13.46/11.43 46
MK280GAN22-1/2**
Dual speed		 230 200~240 50/60 155/210
95/110		 2800/3200
2400/2500		 1150/1300
1000/1050		 32.6/36.8
28.3/29.7		 1.2/0.75
1.02/0.59		 30.48/19.05
25.91/14.99		 74
MK280GAN22-3/4**
Dual speed		 230 200~240 50/60 32/43
26/35		 1500/1600
1200/1100		 620/650
460/450		 17.6/18.4
13/12.7		 0.53/0.45
0.25/0.35		 13.46/11.43
6.35/8.89		 46
34
  • The stated airflow, air pressure, noise levels are measured with housing orifice dia.: impeller Φ +1~1.5mm, at distance: approx. height of impeller + motor frame. The optimal operating data can only be depended on the installation conditions.
  • ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
  • 100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.
  • Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
  • Sinwan reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
To Favourites
Recommend
Print
Question about the product
Details
Info
Details
  Motor Type: Capacitor induction, 2 or 4 pole
  Burnout Protection: Thermal protector
  IP Protection: IP56
  Frame: Aluminum die cast, natural color treatment
  Impeller: Steel metal fan blades integrantly spot welded into rotor for high efficiency
  Bearing: Two high precision permanently lubricated ball bearings
  Rotation: CCW seen on rotor
  Connection: Wire lead
  Weight: 2,500g (5.51 Lbs)
  Dielectric Strength: Over 1 minute at 1,500 VAC, 0.5mA, 50/60 Hz
  Insulation Resistance: Over 100 MΩ at DC 500V
  Signal Output:
  Operating Temp: Ambient non-condensing -30~+80C
  Storage Temp: -40C~+100C (at 65%RH)
  Life Expectancy: 150K hours at 35C, 45K hours at 60C
