S254RAN-11-22-1 Plastic Impeller Dual

Motor Type:Capacitor induction, Inner rotor, 1-phase, 2/4 pole
Burnout Protection:Thermal protector, auto cut-off, auto reset
IP Protection:-
Frame:Aluminum die cast, natural coating
Impeller:7 blades, glass fiber reinforced plastic, rated UL94V-0
Bearing:Two ball bearings
Rotation:CCW seen on rotor
Connection:Wire leads, push-in terminal flat pins
Weight:2,900 g (6.39 Lbs)
Dielectric Strength:Over 1 min. at 1,500 VAC, 0.5mA, 50/60 Hz
Insulation Resistance:Over 100 MΩ at DC 500V
Signal Output:Optional:alarm R/D, tachometer F/G
Operating Temp:Ambient non-condensing -20~+70C
Storage Temp:-40C~+100C (at 65%RH)
Life Expectancy:L10 80K hours at 35C, 40K hours at 60C

WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.
Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
Sinwan reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
