Motor Type:Capacitor induction, outer rotor, 1-phase
Burnout Protection:Thermal protector, auto cut-off, auto reset
IP Protection:Optional:IP56
Frame:Aluminum die cast, natural coating(S280RAN), black(S280RAP) on request
Impeller:7 blades, glass fiber reinforced plastic, rated UL94V-0
Bearing:Two ball bearings
Rotation:CCW seen on rotor
Connection:Wire leads-WB, or push-in terminal flat pins-TB
Weight:3,400g (7.5 Lbs)
Dielectric Strength:Over 1 min. at 1,500 VAC, 0.5mA, 50/60 Hz
Insulation Resistance:Over 100 MΩ at DC 500V
Signal Output:Optional:alarm R/D, tachometer F/G
Operating Temp:Ambient non-condensing -20~+70℃
Storage Temp:-40℃~+100℃ (at 65%RH)
Life Expectancy:L10 80 K hours at 35℃, 40K hours at 60℃
WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.
Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
Sinwan reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
Burnout Protection:Thermal protector, auto cut-off, auto reset
IP Protection:Optional:IP56
Frame:Aluminum die cast, natural coating(S280RAN), black(S280RAP) on request
Impeller:7 blades, glass fiber reinforced plastic, rated UL94V-0
Bearing:Two ball bearings
Rotation:CCW seen on rotor
Connection:Wire leads-WB, or push-in terminal flat pins-TB
Weight:3,400g (7.5 Lbs)
Dielectric Strength:Over 1 min. at 1,500 VAC, 0.5mA, 50/60 Hz
Insulation Resistance:Over 100 MΩ at DC 500V
Signal Output:Optional:alarm R/D, tachometer F/G
Operating Temp:Ambient non-condensing -20~+70℃
Storage Temp:-40℃~+100℃ (at 65%RH)
Life Expectancy:L10 80 K hours at 35℃, 40K hours at 60℃
WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.
Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
Sinwan reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
http://sinwan.eu
Info
Input Power (Watt)
32/37
Max.Airflow (CFM)
1100/1200
Max.Static Pressure (mm)
4.57/3.3
Noise level dB (A)
35
Rated Volt (VAC)
230
Voltage Range (VAC)
200-240
Freq(HZ)
50/60
Ref speed (RPM)
1100/1200
M3/min
13.3/13.7
Max.Static Pressure( Inch/H2o)
0.18/0.13
PQ
8/7
Article No.
S280RAN-22-3
