S280RAP-11-3 Plastic Impeller

S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
S280RAP-11-3 Plastic Impeller
280x280x88.9mm/11x3.5inch
1450 CFM
IP44, Inner rotor
To Favourites
Recommend
Print
Question about the product
Details
Info
Details
Motor Type:Capacitor induction, inner rotor, 1-phase
Burnout Protection:Thermal protector, auto cut-off, auto reset
IP Protection:-
Frame:Aluminum die cast, black color
Impeller:7 blades, glass fiber reinforced plastic, rated UL94V-0
Bearing:Two ball bearings
Rotation:CCW seen on rotor
Connection:Wire leads, or push-in terminal flat pins
Weight:3,950g ( 8.7 Lbs)
Dielectric Strength:Over 1 min. at 1,500 VAC, 0.5mA, 50/60 Hz
Insulation Resistance:Over 100 MΩ at DC 500V
Signal Output:Optional:alarm R/D, tachometer F/G
Operating Temp:Ambient non-condensing -20~+70C
Storage Temp:-40C~+100C (at 65%RH)
Life Expectancy:L10 90K hours at 35C, 50K hours at 60C

WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.
Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
Sinwan reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%

http://sinwan.eu

Info
Input Power (Watt)
32/37
Max.Airflow (CFM)
465/450
Max.Static Pressure (mm)
4.06/2.79
Noise level dB (A)
35
Rated Volt (VAC)
115
Voltage Range (VAC)
100-120
Freq(HZ)
50/60
Ref speed (RPM)
1100/1000
M3/min
13.2/12.7
Max.Static Pressure( Inch/H2o)
0.16/0.11
PQ
6/5
Article No.
S280RAP-11-3
