Motor Type: AC-DC Energy Saving EC Motor
Burnout Protection: Electronically protected
IP Protection: IP55, 56 optional request
Frame: Aluminum die casting motor frame
Impeller: Plastic impeller
Bearing: Maintenance-free two ball bearings
Rotation: -
Connection: Wire leads
Weight: 800 g
Dielectric Strength: 500VAC/min. Max. leakage 500mA
Speed Control: Optional:PWM, S/C NTC thermister on request
Signal Output: Optional:R/D alarm output, tachometer output
Operating Temp: -20~+65C(non-condensing)
Storage Temp: -40~+90C
Life Expectancy: L10 formula 90K hours at 35C, 30K hours at 65C
