SD175SAP (CW/CCW) - Sinwan Reversible Flow Fan Dia.172x152x51.6mm / 6.7x2inch 291 CFM

SD175SAP (CW/CCW) - Sinwan Reversible Flow Fan Dia.172x152x51.6mm / 6.7x2inch 291 CFM
SD175SAP (CW/CCW) - Sinwan Reversible Flow Fan Dia.172x152x51.6mm / 6.7x2inch 291 CFM
SD175SAP (CW/CCW) - Sinwan Reversible Flow Fan Dia.172x152x51.6mm / 6.7x2inch 291 CFM
SD175SAP (CW/CCW) - Sinwan Reversible Flow Fan Dia.172x152x51.6mm / 6.7x2inch 291 CFM
Rated
Volt		 Voltage
Range

Input
Power

 Rated
Current		 Ref.
Speed		 Max.Airflow Max.Static Pressure Noise
Level		 PQ
Curves		 UL
Model No VDC VDC Watt Amp RPM CFM m3/min Inch/H2O mm db(A)
SD175SAP-12H** (W) 12 7~13.2 23 (~39.6) 1.9 (~3.3) 4000 310 8.8 1.29 32.77 60 R
SD175SAP-24H** (W) 24 12~26.4 24 (~40.8) 0.97 (~1.7) 4000 310 8.8 1.29 32.77 60 R
SD175SAP-48H** (W) 48 28~56 23.5 (~48.0) 0.48 (~1.0) 4000 310 8.8 1.29 32.77 60 R
  • ** = "WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
  • Sinwan reserves the right to change data and improve electrical & mechanical design without notice, data tolerance +-10%
Add to Favorites
Print
Inquire
Details
Data
Details
  Motor Type: Microprocessor brushless DC Motor, auto cutoff, auto restart
  Burnout Protection: Electronically protected, polarity protected
  IP Protection: IP55,56,68 optional request
  Frame: Aluminum die cast, black color
  Impeller: 7 blades, glass fiber reinforced plastic, rated UL94V-0
  Bearing: Two ball bearings
  Rotation: CW/CCW, Reversible Flow Fan
  Connection: Wire leads
  Weight: 700g
  Dielectric Strength: 500 VAC/min. Max leakage 500mA
  Speed Control: PWM, S/C NTC thermister (Optional)
  Signal Output: Optional: RD Rotation Detactor, FG Frequency Generator
  Operating Temp: Ambient non-condensing -10~+70C
  Storage Temp: -25C~+70C (at 65%RH)
  Life Expectancy: L10 70K hours at 40C

http://sinwan.eu

Data
Item number
SD175SAP_CW_CCW
