SDB6025PT - Sinwan DC Blower Fan Dia.60x60x25mm 14~6.2CFM

SDB6025PT - Sinwan DC Blower Fan Dia.60x60x25mm 14~6.2CFM
SDB6025PT - Sinwan DC Blower Fan Dia.60x60x25mm 14~6.2CFM
SDB6025PT - Sinwan DC Blower Fan Dia.60x60x25mm 14~6.2CFM
SDB6025PT - Sinwan DC Blower Fan Dia.60x60x25mm 14~6.2CFM
  Motor Type: DC Motor
  Burnout Protection: Locked rotor protection
  IP Protection: IP55, IP67 (Optional)
  Frame: Glass fiber reinforced thermoplastic, rated UL94V-0
  Impeller: Glass fiber reinforced thermoplastic, rated UL94V-0
  Bearing: Ball bearing
  Rotation: CCW seen on rotor
  Connection: Wire leads
  Weight: 51g
  Dielectric Strength: 500 VAC/min. Max leakage 0.5mA
  Speed Control: Optional: PWM, S/C NTC thermister
  Signal Output: Optional: RD Rotation Detactor, FG Frequency Generator
  Operating Temp: -20C~+65C
  Storage Temp: -20C~+75C (at 65%RH)
  Life Expectancy: L10 50K hours at 40C
To Favourites
Recommend
Print
Question about the product
Ask about it
Details
Info
Details
Rated
Volt		 Voltage
Range

Input
Power

 Rated
Current		 Ref.
Speed		 Max.Airflow Max.Static Pressure Noise
Level		 PQ
Curves		 UL
Model No VDC VDC Watt Amp RPM CFM m3/min Inch/H2O mm db(A)
SDB6025PT-05SH** 5 4.5~5.5 3.0 0.6 4500 8.4 0.2 0.6 15.24 45 7 R
SDB6025PT-05HHH** 5 4.5~5.5 2.5 0.5 3500 6.5 0.2 0.47 11.94 35 9 R
SDB6025PT-12SH** 12 7~13.2 7.56 0.63 6000 11.3 0.3 0.81 20.57 59 4 R
SDB6025PT-12HHH** 12 7~13.2 6.0 0.5 5500 10.3 0.3 0.74 18.8 54 5 R
SDB6025PT-12HH** 12 7~13.2 5.16 0.43 5000 9.3 0.3 0.67 17.02 50 6 R
SDB6025PT-12H** 12 7~13.2 2.52 0.21 4000 7.5 0.2 0.54 13.72 39 8 R
SDB6025PT-12M** 12 7~13.2 1.44 0.12 3200 6.0 0.2 0.43 10.92 32 9 R
SDB6025PT-12L** 12 7~13.2 1.08 0.09 2700 5.0 0.1 0.36 9.14 26 10 R
SDB6025PT-24EH** 24 14~26.4 8.4 0.35 8200 15.4 0.4 1.1 27.94 80 1 R
SDB6025PT-24SHH** 24 14~26.4 7.2 0.3 7500 14.0 0.4 1.0 25.4 72 2 R
SDB6025PT-24SH** 24 14~26.4 6.0 0.25 6800 12.6 0.4 0.9 22.86 64 3 R
SDB6025PT-24HHH** 24 14~26.4 4.8 0.2 6000 11.3 0.3 0.81 20.57 59 4 R
SDB6025PT-24HH** 24 14~26.4 3.6 0.15 5000 9.3 0.3 0.67 17.02 50 6 R
SDB6025PT-24H** 24 14~26.4 2.88 0.12 4500 8.4 0.2 0.6 15.24 45 7 R
SDB6025PT-24M** 24 14~26.4 1.92 0.08 4000 7.5 0.2 0.54 13.72 39 8 R
SDB6025PT-24L** 24 14~26.4 1.44 0.06 3500 6.5 0.2 0.47 11.94 35 9 R
SDB6025PT-48SHH** 48 28~56 14.4 0.3 8200 15.4 0.4 1.1 27.94 80 1 R
SDB6025PT-48SH** 48 28~56 9.6 0.2 7500 14 0.4 1.0 25.4 72 2 R
SDB6025PT-48HHH** 48 28~56 7.2 0.15 6800 12.6 0.4 0.9 22.86 64 3 R
SDB6025PT-48HH** 48 28~56 6.24 0.13 6000 11.3 0.3 0.81 20.57 59 4 R
SDB6025PT-48H** 48 28~56 3.84 0.08 5000 9.3 0.3 0.67 17.02 50 6 R
  • ** = "WB" for wire lead type Ball bearing
  • Sinwan reserves the right to change data and improve electrical & mechanical design without notice, data tolerance +-10%

http://sinwan.eu

Info
Article No.
SDB6025PT
