SE825PT

SE825PT

SE825PT 80X80X25

To Favourites
Recommend
Print
Question about the product
Ask about it
Details
Info
Details

  Motor Type: AC-DC Energy Saving EC Motor
  Burnout Protection: Electronically protected
  IP Protection: Ratings on request
  Frame: PBT UL 94-V0
  Impeller: 9 blades, Thermoplastic PBT UL94V-0
  Bearing: Two ball bearings
  Rotation: CCW seen on rotor
  Connection: Wire leads or terminal flat pins connecting
  Weight: 78g
  Dielectric Strength: 1500VAC/min
  Speed Control: Optional:PWM, S/C NTC thermister on request
  Signal Output: Optional:R/D alarm output, tachometer output
  Operating Temp: -10~+70C
  Storage Temp: -40~+75C
  Life Expectancy: L10 70K hours at 40C

http://sinwan.eu

Info
Article No.
SE825PT_80X80X25
