S254RAP-22-3


Motor Type:
Capacitor induction, inner rotor, 2 or 4 pole. Dust particles & moisture protected


Burnout Protection:
Thermal protector, auto cut-off, auto reset, completely dust & moisture protected


IP Protection:
IP66, dust/solid objects & moisture/liquids enclosures protected



Frame:
Aluminum die cast, black coating treatment


Impeller:
7 blades, glass fiber reinforced plastic, rated UL94V-0


Bearing:
Two ball bearings


Rotation:
CCW seen on rotor


Connection:
Wire leads or terminal flat pins


Weight:
2,230g ( 4.9 Lbs)



Dielectric Strength:
Over 1 min. at 1,500 VAC, 0.5mA, 50/60 Hz


Insulation Resistance:
Over 100 MΩ at DC 500V


Signal Output:
Optional: Motor slow down alarm R/D, tachometer speed tacho F/G



Operating Temp:
Ambient non-condensing -20~+70℃


Storage Temp:
-40℃~+100℃ (at 65%RH)


Life Expectancy:
L10 90K hours at 35℃, 50K hours at 60℃

WB" for wire lead type Ball bearing, or "TB" for terminal type Ball bearing
100, 200, 240V or special voltages 12, 24, 28, 38, 42, 48, 380~440~480... 50/60Hz, & dual voltage version available on request.
Dual speed High/Medium 1/2, High/Low 1/3, Medium/Low 2/3, Low/extra Low 3/4 or triple speed 1/2/3 available on request.
Sinwan reserves the right to change data and improve electrical or mechanical design without notice, data tolerance +-10%
